Portable Gasoline Generator

Portable Gasoline Generator
Compact yet powerful, this mini silent petrol generator delivers reliable performance wherever you need it. Built with our self-made, rigorously tested engine, it offers exceptional durability and an unbeatable performance-to-price ratio. Choose from hand start (recoil) or key start with battery. A low-noise muffler ensures quiet operation, with a motorcycle silencer option available.
Premium components include a cast iron camshaft, high-quality carburettor, A++ grade piston, and best-in-class crankcase, all secured with galvanised screws. Available in single or three-phase, with optional volt-meter, T-meter, and protective double panel. Finished in any colour of your choice and packed in strong, foam-lined cartons with wood reinforcement for safe delivery.
Perfect for home backup, outdoor work, and leisure use — silent, portable, and built to last.
Specifications
Specification | Model 1 | Model 2 | Model 3 | Model 4 | Model 5 | Model 6 | Model 7 |
---|---|---|---|---|---|---|---|
Product Name | 1.5–8 kW Gasoline Generator | ||||||
Keyword | Portable Petrol Generator | ||||||
Rating Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
Rating Voltage (V) | 110 / 120 / 220 / 230 / 240 | ||||||
Rated Power (kVA) | 1.5 | 1.8 | 2.0 | 2.5 | 3.0 | 2.7 | 2.8 |
Max. Power (kVA) | 1.7 | 2.0 | 2.2 | 2.7 | 3.5 | 3.0 | 3.0 |
Power Factor (cos φ) | 1.0 | ||||||
Engine Type | 168F | 168F-1 | 170F | 177F | 182F | 188F | 190F |
Model (HP) | 5.5HP | 6.5HP | 7.0HP | 9.0HP | 11.0HP | 13.0HP | 15.0HP |
Category | Single crock, Force air-cooled, 4-stroke, top-installed gasoline engine | ||||||
Cylinder Displacement (cc) | 163 | 196 | 212 | 270 | 337 | 389 | 407 |
Max. Output Power (kW / rpm) | 4.8 / 3600 | 4.8 / 3600 | 5.7 / 3600 | 7.0 / 3600 | 8.0 / 3600 | 9.5 / 3600 | 11.0 / 3600 |
Ignition System | Transistorized magneto | ||||||
Start System | Recoil / E-start | ||||||
Fuel Tank Capacity (L) | 15 | 15 | 15 | 25 | 25 | 25 | 25 |
Fuel Consumption (L/h) | 1.02 | 1.13 | 1.32 | 1.90 | 2.45 | 2.70 | 2.95 |
Continuous Working Time (h) | 13 | 13 | 11 | 13 | 10 | 9 | 8 |
Noise @ 7m (dB) | 65 | 65 | 65 | 69 | 72 | 74 | 78 |
Engine Oil Capacity (L) | 0.6 | 1.1 | |||||
Dimensions (mm) | 615×435×455 | 615×435×455 | 615×435×455 | 620×470×480 | 635×510×485 | 670×510×510 | 692×522×545 |
Net Weight (kg) | 37.5 | 39 | 45 | 62 | 78 | 80 | 85 |
Standard Equipment | Large capacity fuel tank, large capacity muffler, fuel gauge, voltmeter, AVR, oil alert, AC circuit breaker |
