Ride on Concrete Trowel

Ride on Concrete Trowel

This ride-on power trowel dramatically reduces labour intensity and boosts work efficiency—achieving 5 to 8 times the productivity of standard handheld machines. Its heavy-duty dual blades offer superior ground compaction and surface smoothness, significantly enhancing concrete density and finish quality.



Equipped with dual lifting plates for fast adjustment, a mechanical steering system for easy handling, and a pedal-controlled throttle for responsive speed control, the machine is both powerful and comfortable to operate.



Featuring a mid-mounted petrol engine with dual clutch design, plus a 14-litre water tank and fuel tank, it ensures long hours of uninterrupted use. Integrated water spray and front/rear lighting make it ideal for extended or low-light construction tasks.



Perfect for levelling, smoothing, and finishing cement concrete surfaces with speed and precision.

Specifications

Specification 800 Type 1000 Type
Product Name Ride-on Concrete Power Trowel
Model 800 Type 1000 Type
Engine Brand Equipped B&S / Honda / Chinese Petrol Engine B&S / Honda / Chinese Petrol Engine
Engine Power 15 HP 17–24 HP
Blade Size 300 × 140 mm 350 × 150 mm
Blade Number 8 8
Blade Hole Spacing 120 mm (1–3 holes) 120 mm (1–3 holes)
Polishing Pan Diameter 780 mm 980 mm
Polishing Pan Thickness 3 mm 3 mm
Polishing Pan Speed 90–120 r/min 90–120 r/min
Start Mode Electric Start Electric Start
Reduction Box Maintenance-free / Copper Turbine Maintenance-free / Copper Turbine
Fuel Tank Capacity 6.5 L 12 L
Oil Capacity 1.1 L 1.5 L
Power Type 390 Petrol, Single Cylinder 690 Petrol, Twin Cylinder
Automatic Water Spraying Yes Yes
Road Wheel External Carrying Type External Carrying Type
Machine Size (L×W×H) 1700 × 850 × 850 mm 2150 × 1100 × 1150 mm
Weight 270 kg 380 kg
