Valve bag placer
Automatic Bag Placer for Packing Machine — Robotic Valve Bag Placer
Automate bag pick-up, pre-opening and placement for valve bag filling lines — increase throughput, improve safety, reduce labour.
Efficient!
Valve Bag Placer
- The Wiz Machinery Automatic Bag Placer integrates with existing valve bag filling machines to pick, pre-open, and place bags precisely on spouts — eliminating manual handling and increasing line reliability.
- Automate the repetitive, dusty, and safety-sensitive task of hanging valve bags on your filling spouts.
- Ideal for cement, construction materials, food ingredients, chemicals, and agricultural products. Our automatic bag placer handles powders and granular products across diverse sectors — from flour to cement.
- This system is fully PLC-controlled and can be seamlessly integrated with the packaging machine’s PLC, allowing complete process coordination—from bag picking and placing to product filling—via a single control panel.
- Multiple bag placer machines can also be linked with multiple packaging machines for centralised control.
- Its user-friendly design ensures easy operation and maintenance, making it a practical upgrade for both new and existing production lines.
0
bags/hr
0
max bags store
Process flow
1. Bag Supply Preparation
Each automatic bag placer is equipped with two bag carts. These carts alternate automatically to continuously feed bags into the system, ensuring non-stop operation without manual intervention.
2. Bag Pickup
The system automatically detects and picks up an individual bag from the active bag cart using a mechanical arm or vacuum mechanism.
3. Bag Lifting
The picked-up bag is precisely lifted to a specific height by the host machine, aligning it for the next stage in the process.
4. Valve Port Opening
Once positioned, the valve port of the bag is automatically opened, preparing it for accurate placement onto the packing machine.
5. Bag Placement
The opened valve port is carefully positioned and placed over the discharge nozzle of the packing machine, ready for filling.
6. Continuous Cycle Operation
As one bag is placed, the next cart is automatically engaged (when required), enabling continuous, uninterrupted operation for high-efficiency production.
Features
Robotic bag pick & placement
Reliable end-of-arm tooling for consistent placement on spouts.
Pre-opening & bag conditioning
The sequence—including lifting, opening the valve, and positioning the bag on the discharge nozzle—is designed for consistent and smooth performance.
High-capacity bag magazine
Holds up to ~150 bags per single-spout magazine.
Adjustable Speed Settings
Each stage of the bag placing process can be individually adjusted to suit different production speeds and output requirements.
Dust containment & safety
Enclosed pick-box designs and sealed components for dusty or food-grade environments.
Easy integration
Controlled via a PLC system, the bag placer offers easy operation, with the ability to synchronise with packing machines and auxiliary equipment such as fillers, checkweighers and palletizers.
User-Friendly and Easy Integration
Designed for straightforward integration into existing lines, the system is simple to use and maintain, supporting overall process optimisation.
Fast changeover
Modular tooling and adjustable tooling to handle multiple bag sizes and valve widths with minimal downtime.
Throughput options
Up to 280 bags/hour depending on filler speed and product.
Specifications
| Specification | Automatic Bag Placer for Packing Machine |
|---|---|
| Model | WM - DE50 |
| Bag Picking & Placing Speed | 240–280 bags per hour |
| Automation | Fully automated bag placing process |
| Bag Cart Capacity | 50–150 bags per cart (depending on bag thickness) |
